Optec CASAMBI 12W/930 334 lm obraz (Contour)2006
Contour Spotlight (ERCO adapter)
Paintings lighting. Framing attachments enable a sharply defined light beam
Basic characteristics
1223050>0.920LVDEMC
3000lm>334>92ERCO
930lm/10W93 lm/W<0.1s
930lm/10W93 lm/W<0.1s
1 = excellent visual comfort
Bulb
equivalent = 334 lm
equivalent = 334 lm
Technical specifications
| Segment of use: | Resident, Office, Shop |
|---|---|
| Designed for use: | Interior |
| Manufacturer: | ERCO |
| Power consumption: | 12 W |
| Supply voltage: | AC ~ 230 V / 50 Hz |
| Chip name/manufacturer: | ERCO |
| Chip type: | 930lm/10W |
| Chip luminous efficacy: | 93 lm/W |
| System luminous efficacy: | 28 lm/W |
| Power factor (PF): | >0,90 |
| Degree of protection: | IP20 |
| Protection class: | Double |
| Declaration of Conformity: | CE LVD, CE EMC |
| Color temperature: | 3 000 °K |
| Luminaire Luminous flux: | >334 lm |
| Color rendering index: | Ra > 92 |
| Uniform Glare Rate (UGR): | 19 |
| Luminous flux distribution: | Framing (Contour spotlight) |
| Curve of luminosity: | Asymetric |
| Dimmable: | Yes (CASAMBI (BT)) |
| The time at which the light comes on: | 0,1 s |
| Weight netto: | 0.7 kg |
| Body color: | Black |
| Mounting methods: | ERCO (to the track) |
| Lifespan: | 100 000 h |
| Warranty: | 2 y. standard 3 y. prolonged 5 y. project |
| Pcs in package: | 1 |
| Pcs in carton: | 1 |
